Laser Rangefinder

The ultra-compact JT-LDM01 laser rangefinder impresses with its high-quality aluminum housing and allows precise measurements up to 30 meters away. With an accuracy of ±2 mm, you are always up to even the most demanding tasks, while the light weight of just 28 g ensures that you can stow this measuring tool away effortlessly. The uncomplicated charging via USB-C is also impressive and makes the JT-LDM01 a reliable companion for professional applications and ambitious DIY projects.

In addition to exact individual measurements, the device even supports indirect measurements thanks to the Pythagoras function, giving you maximum flexibility. In addition, the JT-LDM01 allows you to quickly and easily determine areas and volumes so that you always have a solid basis for planning your work. In difficult lighting conditions or in larger rooms, the continuous measurement helps you to achieve accurate results and maintain an overview.

Thanks to the high-quality materials and well thoughtout design, the laser rangefinder always works reliably, even under changing conditions. Whether on the construction site, in the workshop or when renovating at home: The JT-LDM01 adapts flexibly to your requirements and can be used in temperatures between 0 and 40 °C without any problems.

Its ultra-compact format makes it ready to hand at all times, and the included lanyard provides additional safety. Rely on reliable performance, consistent precision and advanced design - making measuring a pleasure in any situation.

Specifications

Special features

Up to 30 meters measuring distance
Ultra compact aluminum housing
Rechargeable via USB-C
Area calculation & volume calculation
Continuous measurement & Pythagoras calculation

Measuring range

0,03 - 30 m

Measuring accuracy

± 2 mm, under unfavorable conditions: ± 3 mm

Available units

Meters, inches, feet

Smallest display unit

1 mm

Battery

250 mAh LI-ION battery, rechargeable via USB-C (5 V, 1 A)

Laser class

2

Laser wavelength

620 - 670 nm

Laser strength

< 1 mW

Housing material

Aluminum

Measurement methods

Single measurement, continuous measurement

Calculation methods

Area calculation, volume calculation, Pythagoras

Measuring position

Adjustable: front edge / rear edge of the measuring tool

Operating temperature

0 - 40 °C

Storage temperature

-20 - 60 °C

Air humidity

80 % (not condensing)

Additional information

Dimensions

68,5 x 22 x 13,5 mm

Weight

28 g

Items shipped

JT-LDM01, USB-C charging cable, lanyard

EAN

4250236828961

Article No.

JT-LDM01
