0.96" OLED Display

The compact 0.96 inch (approx. 2.44 cm) OLED display is the perfect solution for your projects. Thanks to the flexible control via I2C or SPI, it can be easily integrated with Arduino, Raspberry Pi and other microcontrollers or single-board computers.

OLED technology ensures brilliant, high-contrast displays without the need for backlighting, as each pixel is self-luminous. This not only results in outstanding image quality, but also particularly low power consumption.

With this display, you can present your

Specifications

Model

OLED Display

Controller

SSD1306

Display size

0,96“ (2,44 cm)

Special feature

Small display with high resolution,
Easy to connect,
Universally applicable

Power supply

3,3 - 5 V

Logic level

3,3 V

Resolution

128 x 64 pixels

Background color

Black

Display color

Blue

Interface

I2C, SPI

Additional information

Dimensions

27 x 28 x 11 mm

Weight

4g

Items shipped

Display

EAN

4250236827391

Article No.

SBC-OLED01V2
