ESP32 Cam

ESP32 Cam

ESP32 Cam

The ESP32-Cam is a compact camera module with low power consumption, multiple interfaces ( SPI / I²C / UART / PWM ) and is therefore suitable for many IoT applications and home projects ( e.g. video surveillance, QR identification and much more ). It is based on the popular ESP32, has a 2 megapixel camera with integrated LED flash and an SD card slot ( up to 4GB memory ), allowing images to be saved directly to the memory card.

Thanks to the BT radio and Wifi interface, the ESP32 camera module can communicate wirelessly, so it can be integrated into your own network (Internet access) and the images can be saved on a web server.

Specifications

Specifications

Camera

2MP OV2640

Photo formats

JPEG, BMP, Grayscale

Processor

Dual Core-ESP32 160 MHz

Besonderheiten

Bright Flash-LED, integrated antenna

Interfaces

UART, SPI, I2C, PWM, Wi-Fi, BT-wireless connection

SD-Card slot

Up to 4 GB

SPI Flash

32 Mbit

RAM

52KB SRAM + 4MB PSRAM

Supply voltage

5 V

Operating temperature

-20°C ~ 85°C

UART standard Baudrate

115200 bps

Power consumption

6mA in deep sleep; 180 mA without flash; 310 mA with flash at max. brightness

Security

WPA, WPA2, WPA2-Enterprise, WPS

Dimensions

27 x 40,5 x 4,5 mm

Items Shipped

Camera module, camera

EAN

4250236818016

Article No.

SBC-ESP32-Cam
